Visual Studio 2013 March 2014 Update has been released

March 3rd, 2014 by Tobias Zimmergren

Today, Microsoft announced the release of Visual Studio 2013 March 2013 Update which have additional features, project types and support for some of the enhancements that comes with Office 2013 SP1 and Office 365. So if you’re a developer targeting Office 365, Office 2013 or SharePoint Server 2013 it may be a good idea to go grab the update and install it now.

SAP Data Source in your Cloud Business Application


As quoted from the Visual Studio blog:

The March 2014 Update also offers first class support for SAP Netweaver Gateway. When connecting CBA to SAP, it honors SAP annotations for Phone, WebAddress, and Email; speeding up your configuration of entities consumed from SAP Netweaver Gateway.

While this may seem like a trivial update, I know this is a popular requirement from a lot of my clients. I don’t think this is the last data source type we’ll see in the list of available types, which is ever growing:


Integrating new document features in your Cloud Business Applications

One of the cool features, which I lacked in one of my CBA projects in the past, is the integration of native controls for managing documents in a library that your CBA is connected to. With the latest update, you get the ability to create new documents in your library from the CBA interface.

When you attach your application to a SharePoint host-web document library, the application will be integrated with a set of new document controls, which allows your users to create new Office documents (either blank documents or from document templates that are available in the attached document library), open documents in Office Web App or Office client, and upload existing documents. All of these are provided by the tools without requiring any extra coding from you.

Picture from blogs.msdn.com, as per the article mentioned in the introduction.

To add such a control and work with these types of controls, you simply have a new option here in the CBA Screen design interface:


Apps for Office Development enhancements

Some of the additions to the Office App development toolset are mentioned:

Office 2013 SP1 and Office 365 supports PowerPoint content apps, Access Web App content apps and allows your mail app to be activated in compose forms (i.e. when users are writing a new email message or creating a new appointment). Office Developer Tools for Visual Studio 2013 – March 2014 Update supports all of these new app types across the development cycle from project creation, manifest editing, programming, debugging to publish.

Apps for SharePoint Development enhancements

There’s some additions to the experiences for developers when creating SharePoint Apps.

With the latest release of the tools, we now can switch the App project to target Office 365 or target an on-premises installation of SharePoint. It’s a new property in the SharePoint project settings dialog:


The app for SharePoint tooling now allows you to target your app exclusively to SharePoint Online in Office 365, or target to an on-prem SharePoint Server 2013 (which can also run in SharePoint Online). Through a simple switch in the app for SharePoint project properties page, the tools will update the SharePoint version number and the SharePoint Client Components assembly references used in your project accordingly.

Another pretty neat thing is the support for MVP in client web parts:

To enhance the support with ASP.NET MVC web applications, we added MVC support for client web part pages in this update. If your app for SharePoint project is associated with an ASP.NET MVC application, when you add a client web part and choose to create a new part page in the client web part creation wizard, a client web part controller and a default view will be added, following the MVC pattern.

Wrap up

I’ve been trying these things out really quick now, and I must say the small but constant flow of enhancements and additions with the new update cadence for all Microsoft products is pretty impressive. Visual Studio 2013 hasn’t been around for that long, but we’re still seeing new updates being published frequently. It is easier than ever to keep up with new development techniques and tools, and no need for exhausting waiting periods.

Read the full story on MSDN Blogs: Announcing Office Developer Tools for Visual Studio 2013 – March 2014 Update

Author: Tobias Zimmergren
www.zimmergren.net | www.tozit.com | www.sharepointdiscussions.com | @zimmergren

Introduction

When dealing with SharePoint development, there’s tons of things to consider. There’s the aspects of code quality, aspects of proficient testing taking place and of course having a reliable process to re-do and fix anything that comes up along the way. Most importantly in my opinion is to not do all iterative work manually over and over. Most of these things are part of any common ALM (Application Lifecycle Management) cycles in a modern-day development team. In this article I’ll talk briefly about how I’ve set up most of my recent projects with routines for the daily iterative development work. This includes Continuous Integration, Nightly Builds, Automated SharePoint Deployments and Automated UITesting. Pretty slick.

Background: Why automate?

One of the most common questions I’m getting today when I introduce the concept of code and deployment automation is "Why?". Why would you invest time to set up an automated environment for iterative builds, deployment and automated tests? For obvious reasons (to me) I shouldn’t need to answer that question because the answer lies within the question itself. That’s just the point – it’s automated and you don’t have to do it yourself over, and over, and over.. and over and over and over again!

As a quick go-to-guide for automation benefits, this should make do:

  • Continuously finding problems and fixing them in time.
  • Revert the entire code base back to a state where it was working, in case trouble arises.
  • Early warnings of things that could be a potential danger to the success of the project.
  • Frequent check-in policies forces developers to validate their code more often.
  • We can iteratively have an up-to-date testing environment for stakeholders to verify our work continuously.
  • Automate testing by PowerShell.
  • Automate UI Testing.
  • Etc etc etc.

The list can grow pretty long, and I’ll try to cover a pro/con list of things to consider in the ALM process, but for now I think it’s important to focus on what’s important for your team. For me and my teams the most important thing is to make the processes more efficient and managing some of the daily tasks automatically. In one of my latest projects I’ve taken the time to enforce a new type of development routine for the team which did not exist before – an iterative development process. This has been key to our development in the upgraded SharePoint solutions where we’ve upgraded older projects from SharePoint 2010 to SharePoint 2013.

See my previous article about Iterative Upgrade Process. It discusses another type of automation that I set up – namely a full SharePoint 2010 to SharePoint 2013 upgrade – every week – before the real upgrade finally approaches.

So if the "why’s" are clear, let’s move on to an overview of what the process could look like.

Implementation: How are we enforcing code- and test automation?

First of all, our main process of automatic development looks something like this:


This is similar to one of the processes I’ve introduced in one of my projects, but as always it’s individual for each project and can vary quite widely with your requirements and setups. Once we’ve done enough iterations and fixes in this simple ALM cycle, we move on to pushing this out to the production environments. But before we get into that, let’s break these steps down a bit:

Develop

During the development phase we focus on getting things done .Taking the collected requirements, nailing them down into a technical implementation and finally checking the code into our code repository. This is the first step of the technical ALM cycle where we actually start to implement the code to fulfill the requirements. But it can also be the last step in the cycle, where bugs have been reported in the "Test & Verification" step, resulting in additional code fixes – which causes the cycle to start all over. For most people this is common sense, and in most experienced teams there are some type of ALM routines in place.

Check-in

When you commit or check-in your code, we can set up rules for the actual check-in. In my case there’s always a few things I tend to do:

  • Build projects and package SharePoint solutions to make sure there’s no basic issues in the project files etc.
  • Execute tools to check the quality of the code, for example the SPCAF tool which is doing a good job of analyzing the packages and resources.
  • Automatically deploy the new packages to a dev-test farm for quick tests by the developers themselves.

Automatic code verification

So as mentioned in the earlier step, we perform automatic verification of various things in our code and packages. You can use the code analysis tools for this, and the SPCAF tools and so on. I will automatically fail the build instantaneously if there are any errors reported, which will cause the build server to e-mail the entire team saying "the latest build broke, here’s why…". The reason for having the build server notify everyone is of course that we should be aware of any issues that occur due to our recent changes – better have everyone know about it than nobody.

In short, we can perform these types of tasks here:

  • Unit Tests (if any)
  • Code analysis
  • SPCAF analysis for SharePoint artifacts
  • etc etc.

Automatic deployment to dev-test farm

When we check-in, we perform a new deployment on the developer test environment, which is a separate farm setup for only the developers to verify their changes and code. Each time a check-in is found in the TFS, we trigger a new deployment to this environment. If a developer is doing tests in the environment for some reason, he/she can flag to the build server that no builds should push any deployments until he/she is done with their tests. Then the build server will pick it up right where it left off before pausing.

Automatic deployment to pre-production farm

After the code is automatically verified and the solution packages are flagged as OK we proceed with deploying the packages to a test environment. This is also a fully automated step but instead of having this triggered on every check-in I’ve chosen to trigger this once per day in my current setup. The reason for this is that we generally want a better uptime on this environment so we can do some actual tests both automatically and manually. I’ve set up rules that first checks that everything went fine when deploying to the dev-test environment. If not, it’ll flag it as a failed build – otherwise it’ll continue to do the full deployment in the pre-production environment as well.

Our pre-production environment is a place where more of the UAT and QA tests happen. We have this environment connected to the proper Domain (AD), proper services and the exact same setup (and even content) as in our production environment. Read more about how we duplicate the content in my previous article, more precisely on the "Copy fresh databases" section.

Summary of the pre-production environment: An almost exact replica of the actual production environment. Proper, life-like tests can be performed here.

Automatic SharePoint & UI Tests

One of the coolest things we’ve got setup are something called UI Tests. If you haven’t seen these before, I urge you to take a look here: MSDN – Verifying Code by Using UI Automation.

With our coded UI Tests, we can simply record logical tests in the UI from our web browser, have Visual Studio convert these recorded actions into a sequence of commands in C# which then are executed automatically once they are run. We’ve made sure that our build server are executing the UI tests on a remote machine, enabling us to test graphical changes and things in the user interface by automatic measures so we don’t have to do this every time ourselves. This is awesome. I promise this is very, very awesome.

On top of the UI tests that we can have automated, we can also have some logical tests performed by PowerShell. In this step we also conduct generic tests to make sure we can create all types of sites based on our templates, that we can change all settings that we have designed in our applications, that we can create all types of lists and so on. In other words: Automating the boring dirty work that otherwise may be very redundant and you normally fall asleep while doing ;-)

Technicalities: Team City as a build server

All of the aforementioned tasks are things that happen automatically by utilizing a build environment. Personally I am pretty hooked on Team City these days. Best part is that it’s free for up to 20 configurations. Cor blimey!

Why use this specific build server? Some people argue that using a TFS build server is the best, some argue that Jenkins beats all else, some argue that Team City is the most awesome tool in the world and so on. They are all good, and they all serve a purpose. For me, the core benefits of Team City are:

  • Installation is done in less than 1 minute (pow!)
  • Configuration and setup of new builds is as easy as 1-2-3
  • Build agent statistics to keep track of build performance etc.
  • It works with multiple version control systems out of the box

TeamCity supports a broad range of version controls out of the box, from the most popular ones to somewhat deprecated but still used systems.

For a single build TeamCity can take source code from several different VCS repositories. You can even mix different types of VCS.

I’m not going to sell you either TeamCity or any other build server, you can just have a look for yourself at the various options there are out there:

My obvious recommendations falls on TeamCity and TFS. It all comes down to where you are, what the projects and budgets look like and what features you’re prone to have included. Some of my projects are on TFS build and some are with TeamCity – most of them in TeamCity actually.

In a future post I might describe in more detail how I’ve technically set everything up for my build environments.

Build Server Configuration: Setting up proper routines

It doesn’t really matter which build server configuration you prefer, as long as it fulfills your requirements. My normal requirements in any type of long-running project for example intranets may look like this:

Continuous Integration

  • Configure a trigger to automatically execute a build, package and code analysis on each check-in.
  • Deploy to dev-test on each check-in

Nightly Deployment

  • Configure a trigger to automatically execute a build, package and code analysis each night.
  • Configure a trigger to automatically execute a deployment to dev-test and pre-production each night.

Weekly Deployment

This is a special configuration that doesn’t really tie into just this ALM cycle, but also to my previously described "Iterative Upgrade Process" cycle. Every week in a current project, we’re tearing down the entire SharePoint environment and we’re building it up again automatically and performing an upgrade. This configuration can trigger that full scheme of things, but it can also be used to just deploy all the latest artifacts. Hence, it’s a pretty special step that we manually trigger today in order to keep the chaos to a minimum.

PowerShell Verification Tests & Nightly UI Tests

By using PowerShell to verify that artifacts exist, can be created and seemingly contain the right properties and by using coded UI tests to perform recorded tests of UX interaction tasks, we’re pretty confident that we’re continuously finding out any issues along the way with less manual work.

As always though; The tests are only as good as the person who wrote them – if you create bad tests, the results will be bad. Keep this in mind and don’t just trust the green lights :-)

Visual overview: Common setup in my projects

My thoughts are along the lines of "the less work you have to manually do yourself, the more work you get done" which are pretty common if you’re into making routines more efficient. I’ll try to describe from a birds perspective what our routines are technically doing by showing you an awesome visualization of my most common type of setups. Following is an illustration of my setup, and below the illustration I’ll describe each section more precisely:


Description of the legend

In the legend (the gray box) you can see that I’ve marked some of the areas in different colors.

Developer Area is where the devs are playing around. Nobody else are touching those environments.

Build Master Area is where the build master (usually me) and potentially a few more designated build administrators hang out. Nobody else are allowed on this environment – it is strictly locked down to only the few people with the required skillset to configure them. If we make a mistake here, we could easily screw up our deadlines in the projects.

Dev Test Farm is where the developers do their initial tests. A rather simple environment with only one goal: Successfully deploy the packages and activate the required artifacts.

Pre-Production Farm is where the artifacts are deployed right after they are verified in the dev-test environments. When we push things to this environment we enable the business decision makers and product owners to get in the game and finally try out what we’ve created. Normally this means that they perform initial requirement matching (that is; did we create what they wanted) and then we’ll connect parts of the organizations users in order to perform the UAT (User Acceptance Tests) properly. Once that is done, and we’ve iterated the cycles enough times to fix all the bugs (yay!) then we’ll push it on to the production environment.

Production Farm is where everything is going live. This is the real deal, and nobody has any access to this environment except the farm administrators. The exception is that the build environment have permission to remotely deploy SharePoint solution packages and execute the required PowerShell commands in order to successfully (and automatically) ensure that the proper artifacts are deployed in a safe manner. We don’t want to allow people to perform manual deployments here! Hands off please :-)

Summary

Well that’s a short story about what my current ALM adventure looks like. I’ve been rigging up some pretty cool environments lately, and I’m loving every bit of it. The confidence of automation is unbeatable – not to mention how much time we actually save.

I could easily hand any of my clients a presentation saying how many man-hours they’ve saved by investing the hours needed to set this up. Priceless!

In the future I might write about the technical implementation of the build servers and so on, but that’ll be a post for another time.

Enjoy.

So today we launched Pointbird.com, let’s celebrate!

November 29th, 2013 by Tobias Zimmergren

Introduction

The last few weeks and months I’ve been busy setting up the foundation for a new set of products we’re developing. We call them Pointbird. The story behind the name is a tale for another time.

Simple but powerful plugins, products and solutions for SharePoint and other services – that’s what we’re currently building. We’ve also simplified licensing so that all our customers can easily understand our model and implement our solutions without any trouble! Easy as 1-2-3.

pointfinal-for-sidebar

Products

We’ve got a set of products lined up in our respositories that are in testing and conceptual phases. However we’ve already launched a few products that we’ve experienced as the most popular requirements from our customers in the projects I’ve been involved in the last few years. Nobody had found a solution for these common problems, so I drew some sketches and then we started creating them. Some are small, others more complex – but they all offer value to our clients and that’s the most important thing for me.

Pointbird Short Url

So the Short Url product, as the name implies, is a product that can shorten url’s of items in SharePoint lists and libraries.

It’s pretty slick and for the user it’s just a matter of clicking one link in the ECB menu:

We’ve actually already implemented this solution at a few clients, and today as soon as we launched we had a few copies sold during the first few hours. Wohoo!

Pointbird Zip Saver

A common request from a lot of my clients I’ve been working with is to be able to select specific files from a library and then just download them all, including folders. Requirements were simple and very clear, so that’s exactly what we implemented – a “Zip Saver” solution that can download multiple files at once, including folders, and presents them nicely in a zip-file. The zip-file contains the exact same structure as your library that you chose to download. Neat! Very neat!

The Pointbird Zip Saver is a rather popular demand and we’ve implemented this in a few organizations already as well.

Pointbird Notify

A very simlpe yet smooth solution for displaying ad-hoc messages to your users in your various sites and site collections. A popular request is to instead of using a portal start page news list or announcement list, to be able to push out messages to your users in a more persistent and focused way. With the Pointbird Notify solution you can simply create a new list item in a special list containing announcements, and it will automatically display it for your users with the settings you specify. Awesome.

Summary

That’s it. No more marketing – we’re done for now. Hope you enjoy it :-)

Author: Tobias Zimmergren
http://www.zimmergren.net | http://www.tozit.com | @zimmergren

Introduction

If you haven’t followed the trend today, you’ve most certainly missed out. The Office 2013 and SharePoint 2013 preview versions were released to the wild today. Steve Ballmer did a LIVE pressrelease where he revealed that the new versions of Office and SharePoint are now officially available for public beta consumption. This is pretty amazing news, so I’ll just leave you with the following information and links and you can be certain that I’ll update this blog regularly with content of SharePoint 2013 awesomeness from this day forth :-)

office15

Download the SharePoint 2013 preview binaries

You can find some of the relevant downloads right here:

SharePoint 2013 binaries

SharePoint Designer 2013 binaries



SharePoint Server 2013 SDKs



Microsoft Office Web Apps Server 2013



Duet Enterprise for SharePoint 2013 and SAP 2.0



Enjoy – and see you on the other side :-)

Author: Tobias Zimmergren
http://www.zimmergren.net | http://www.tozit.com | @zimmergren

Introduction

A while back an announcement was made that TFSPreview.com had been made available for general testing. Various bloggers at Microsoft put an invitation token in their MSDN blogs so everyone can have a go at it.

In this article series we’ll take a very quick look at what the hosted TFS solution by Microsoft looks like.

Articles currently in the series:


Getting your first scheduled build up and running

In order to get a scheduled build that talks to your TFSPreview repository, you’ll need to follow these steps and make sure the prerequisites are fulfilled.

Prerequisites

Note: If you don’t have SharePoint 2010 installed, the installer have an option for installing SharePoint Foundation 2010 for you. In my case however, I’ve got SharePoint Server 2010 Enterprise running already.

Installing the package

First of all, launch the ISO file that was extracted from the downloaded package and you should see this screen:

We want to install Team Foundation Server before we proceed, so choose the first option under the Install headline, which will bring you to this dialog:

You’ll need to accept the EULA and if you’re awesome you’ll keep the second checkbox checked so Microsoft can review any issues that may be encountered during the process so they can have a look at them pre-RTM. Click Continue and then click Install Now in the dialog that follows:
ScreenShot1300

You may or may not need to reboot the computer while it’s performing the installation, depending on whether you’ve had some of the prerequisite artifacts installed prior to the installation or not.

Now just sit tight for a while as the installer takes care of the installation for you. Grab a newspaper, get a coffee, check some important stuff on Twitter or simply multitask with other things while you wait.

When it’s done, you’ll have a few options of what type of installation you want to do:

Please note: At this point you have several options for how to proceed with your installation. You can now choose one of the following installation options:

  • Configure Team Foundation Application Server
  • Configure Team Foundation Server Proxy
  • Configure Team Foundation Build Service
  • Configure Extensions for SharePoint Products

In my case I’ll be choosing the "Configure Team Foundation Build Service" since I only need the actual Build Agents and Build Service – the TFSpreview.com is hosting the actual TFS server.

Next step will present you with a dialog like the following, where you’ll have to choose what default team project collection to utilize for the build server. Since we don’t have TFS installed the box is currently empty, but fear not for your TFS server is hosted in the cloud (tfspreview.com, remember?) so we’ll just have to go and add that connection as well.

Click the "Browse…" button to open the dialog for choosing your TFS connection

If you haven’t already connected to a TFS server, this dropdown will be empty. Click "Servers…":

Click the "Add…" button:

Finally enter the URL to your TFS collection and click "OK":

You will see a dialog that enables you to log in to the services (use the Login details you signed up with for tfspreview.com):

When the sign-in is completed you’ll see that you now have a list of TFS collections. Choose your DefaultCollection (or otherwise) and click "Connect":

It should hopefully say something like this, telling you there’s no build servers unless you’ve already configured it previously:

In the next dialog I’ll choose "Use the default setting" for my setup:

In the next dialog you’ll have to choose credentials for your build rig. I’m using a dedicated domain account called SHAREPOINTSPBuild:

Make sure you validate the configuration and then press "Next"

If awesomeness is found on your machine, it should look something like this:

Click the "Configure" button and let the installer have its way for a while. Hopefully all these fancy green icons will show you that things went smoothly:

With that done, in the next dialog you’ll see a nice "Success" message and you’re ready to start creating and work with your build agents:

Validate the Build Server

On your Start Menu, you should find the following new shortcut:

Clicking the "Team Foundation Server Administration Console" should bring you forth the following dialog where you can validate that your machine is properly up and running with a build server and agents. Click the "Build Configuration" option in the menu to the left and make sure your build agents are running under the controller:

Summary

If you’ve followed along with the steps in this post you’ll see how easy it is to get up and running with creating a build server (controllers+agents) for your TFS. In this case, I chose to do a connection to the TFSpreview-hosted TFS account.

In my next post in this series I’ll talk about how you can create a new build from Visual Studio 2010 from your dev-machine and have it automatically build on this build server. Gotta love automation!

Enjoy.

Sweden SharePoint User Group – Malmö / Stockholm

January 30th, 2012 by Tobias Zimmergren

Introduction

The Sweden SharePoint User Group (SSUG) is a non-profit organization where we continuously  provide meet-ups and presentations about SharePoint in Sweden.
There’s no doubt that everyone’s been very busy the last year and things aren’t about to change now. As we head deeper into 2012 I’m sure we’ll have plenty of awesome SharePoint-related meetings and conferences to attend!

The group started in Stockholm several years ago when Me (Tobias Zimmergren), Göran Husman, Wictor Wilén and Daniel Bugday decided to join our forces and provide a common ground for people in Sweden that are interested in SharePoint.

We’ve conducted several meetings in Stockholm, a few meetings in Gothenburg and unfortunately only one meeting in Malmö. Things are about to change!

With our new establishment of TOZIT AB in the region, I’ve decided to shorten down the long trips I’ve previously had and focus my attention to this region (Öresundsregionen – Helsingborg/Lund/Malmoe/Copenhagen etc.) – this means more time for the SSUG (Sweden SharePoint User Group) in Malmö as well.

Upcoming Event – Malmö

During late February or early March we’ll have our first meeting since 2008, when myself and Carsten Keutmann did presentations on SharePoint Online and WSPBuilder.

Agenda: TBD

Location: Malmö

Date & Time: During March

Upcoming Event – Stockholm

Update: The details for the SSUG Event in Stockholm have been published, and you can sign up and read more here: http://ssug.eventbrite.com/

Agenda:

  • Mattias Karlsson, Microsoft: Talks about Microsoft PFE
    How does the Microsoft support work? What does a PFE do?
  • Wictor Wilén, Connecta: Talks about the MCM and MCA Programs
    What are the Microsoft Certified Masters and Certified Architect programs?
  • Session 3: To Be Decided
    TBD

Location: Microsoft HQ, Akalla (Stockholm)

Date & Time: March 15th, 18:00 CET

Sign up here: http://ssug.eventbrite.com/

Sponsors and Speakers

The routines for our meetings is that we’ve got a sponsor to host the meeting (provide meeting rooms, projectors and food/beverages) and we’ve had one or more speakers during an evening.

We’re currently looking for:

  • Meeting Sponsors: Where you provide your offices or conference rooms for our meetings
  • Speakers: Where you talk about whatever interests you in SharePoint. Here’s some of the popular focus areas we’ve had speakers talk about before:
    • Focus: Development
    • Focus: Architecture
    • Focus: End User Adoption
    • Focus: No-Code Solutions
    • Focus: Marketing
    • Focus: Show Cases / How-We-Did-It

See you soon at a local SSUG meeting!

Enjoy.

Author: Tobias Zimmergren
http://www.zimmergren.net | http://www.tozit.com | @zimmergren

Introduction

A while back an announcement was made that TFSPreview.com had been made available for general testing. Various bloggers at Microsoft put an invitation token in their MSDN blogs so everyone can have a go at it.

In this article series we’ll take a very quick look at what the hosted TFS solution by Microsoft looks like.

Articles currently in the series:


Connect Visual Studio 2010 to your new hosted team project

In order to be able to connect to the hosted TFSPreview team project, you’ll need to comply with the prerequisites I’m listing here.

Prerequisites

Hook up Visual Studio to your new repository/project

Alright, if you’ve downloaded and installed KB2581206 (which means you’re spinning VS2010 SP1 already) you are read to connect. The procedure to connect to the hosted TFS service is basically the same as if you were to connect to any other TFS repository, which is easy and awesome.

In Visual Studio 2010 SP1, simply make these smooth ninja moves and you’re done:

Make sure to fetch the URL of your account (As seen in your dashboard, like depicted below):

Enter this URL in the Visual Studio 2010 dialogs and we’re ready to kick off:

It’ll ask you for your credentials which you need to use to verify your account details:

You should now be authenticated and your repository should be available:

You’ll go ahead as you normally do and choose the projects that interests you and then you’re basically done:

Your Team Explorer should contain your TFS project and you should be able to work with it as you normally would from Visual Studio 2010:

This means you’ve got all of your standard tasks and operations available straight from VS 2010 (So you don’t have to go to the website to make changes …):

Summary

Easy enough. As soon as you’ve downloaded the required tooling to get connected, you can hook up your new cloud-hosted team project in Visual Studio 2010 without any problems. Give it a spin, it flows quite nicely!

Enjoy.

Author: Tobias Zimmergren
http://www.zimmergren.net | http://www.tozit.com | @zimmergren

Introduction

SharePoint 2010 developing for performance article series:
In this series of articles I will briefly introduce you to some key concepts when it comes to developing for performance in our SharePoint 2010 applications.

Related articles in this article series

Part 8 (this article):
As most of you know, in any ASP.NET project (SharePoint included) there’s something you know as ViewState.  With the ViewState we can persist state of our properties in the page controls and objects across postbacks that happen in our solutions. If we are not careful and plan the usage of ViewState properly, we can end up with a performance hit that will slightly decrease the performance in the page rendering process.

In this article we will take a look at what impact the ViewState can have if we “forget about it”, and of course how we can prevent our pages from being unnecessarily big in page size.

ViewState in our SharePoint projects

If you’ve been developing SharePoint projects of any type, you’ve most certainly been doing some kind of asp.net UI development as well. (Application Pages, Web Parts, User Controls and so on) that are inheriting the asp.net capabilities and hence the ViewState.

What you should know as an ASP.NET developer: Be sure to know when you should, or shouldn’t use the ViewState. You can disable the usage of ViewState for certain components, or the entire page.

Performance considerations

With an increased ViewState you get an increased Page Size which in turn obviously means that the page will take a bit longer to render.

We’ll take a quick look at how the performance can differ when we’re using ViewState and when we’re disabling the ViewState in a SharePoint project.

Taking a look: ViewState

In order for us to really understand what impact the ViewState can have on the page rendering process, we’ll dig into the details of the what the ViewState looks like. To do this we can check out the source of the rendered page, and of course we’ll rely on our faithful squire; Fiddler2.

Before we’ll start digging with the Fiddler2-application, we can simply check the Page Source of any given page being rendered and we’ll most likely find a heap of ViewState madness going on in there.

In my sample application that only consist of a simple GridView control and a few rows of data – the ViewState is turned into this:

 <input type= "hidden "



  name= "__VIEWSTATE "



  id= "__VIEWSTATE "



  value= "/wEPDwULLTE5NjIxMzI1MDIPZBYCZg9kFgICAQ9kFgQCAQ9kFgICDw9kFgJmD2QWAgIBD



  w8WAh4HVmlzaWJsZWdkZAIDD2QWBgIRD2QWBGYPZBYEAgEPZBYCZg9kFgQCAg9kFgYCAQ8WAh8Aa



  GQCAw8WCB4TQ2xpZW50T25DbGlja1NjcmlwdAVdamF2YVNjcmlwdDpDb3JlSW52b2tlKCdUYWtlT



  2ZmbGluZVRvQ2xpZW50UmVhbCcsMSwgMSwgJ2h0dHA6XHUwMDJmXHUwMDJmc3BmJywgLTEsIC0xL



  CAnJywgJycpHhhDbGllbnRPbkNsaWNrTmF2aWdhdGVVcmxkHihDbGllbnRPbkNsaWNrU2NyaXB0Q



  29udGFpbmluZ1ByZWZpeGVkVXJsZB4MSGlkZGVuU2NyaXB0BSFUYWtlT2ZmbGluZURpc2FibGVkK



  DEsIDEsIC0xLCAtMSlkAhUPFgIfAGhkAgMPDxYKHglBY2Nlc3NLZXkFAS8eD0Fycm93SW1hZ2VXa



  WR0aAIFHhBBcnJvd0ltYWdlSGVpZ2h0AgMeEUFycm93SW1hZ2VPZmZzZXRYZh4RQXJyb3dJbWFnZ



  U9mZnNldFkC6wNkZAIDD2QWAgIBD2QWAgIDD2QWAgIBDzwrAAUBAA8WAh4PU2l0ZU1hcFByb3ZpZ



  GVyBRFTUFNpdGVNYXBQcm92aWRlcmRkAgEPZBYCAgUPZBYCAgEPEBYCHwBoZBQrAQBkAjMPZBYCA



  gcPZBYCAgEPDxYCHwBoZBYCAgMPZBYCAgMPZBYCAgEPPCsACQEADxYCHg1OZXZlckV4cGFuZGVkZ



  2RkAkcPZBYCAgEPZBYCAgEPPCsADQIADxYEHgtfIURhdGFCb3VuZGceC18hSXRlbUNvdW50AukHZ



  AEQFgNmAgECAhYDPCsABQEAFgQeCkhlYWRlclRleHQFAklEHglEYXRhRmllbGQFAklEPCsABQEAF



  gQfDgUFVGl0bGUfDwUFVGl0bGU8KwAFAQAWBB8OBQtEZXNjcmlwdGlvbh8PBQtEZXNjcmlwdGlvb



  hYDZmZmFgJmD2QWNAIBD2QWBmYPDxYCHgRUZXh0BQEwZGQCAQ8PFgIfEAUNU2FtcGxlIEl0ZW0gM



  GRkAgIPDxYCHxAFIVppbW1lcmdyZW4ncyBQZXJmb3JtYW5jZSBTYW1wbGUgMGRkAgIPZBYGZg8PF



  gIfEAUBMWRkAgEPDxYCHxAFDVNhbXBsZSBJdGVtIDFkZAICDw8WAh8QBSFaaW1tZXJncmVuJ3MgU



  GVyZm9ybWFuY2UgU2FtcGxlIDFkZAIDD2QWBmYPDxYCHxAFATJkZAIBDw8WAh8QBQ1TYW1wbGUgS



  XRlbSAyZGQCAg8PFgIfEAUhWmltbWVyZ3JlbidzIFBlcmZvcm1hbmNlIFNhbXBsZSAyZGQCBA9kF



  gZmDw8WAh8QBQEzZGQCAQ8PFgIfEAUNU2FtcGxlIEl0ZW0gM2RkAgIPDxYCHxAFIVppbW1lcmdyZ



  W4ncyBQZXJmb3JtYW5jZSBTYW1wbGUgM2RkAgUPZBYGZg8PFgIfEAUBNGRkAgEPDxYCHxAFDVNhb



  XBsZSBJdGVtIDRkZAICDw8WAh8QBSFaaW1tZXJncmVuJ3MgUGVyZm9ybWFuY2UgU2FtcGxlIDRkZ



  AIGD2QWBmYPDxYCHxAFATVkZAIBDw8WAh8QBQ1TYW1wbGUgSXRlbSA1ZGQCAg8PFgIfEAUhWmltb



  WVyZ3JlbidzIFBlcmZvcm1hbmNlIFNhbXBsZSA1ZGQCBw9kFgZmDw8WAh8QBQE2ZGQCAQ8PFgIfE



  AUNU2FtcGxlIEl0ZW0gNmRkAgIPDxYCHxAFIVppbW1lcmdyZW4ncyBQZXJmb3JtYW5jZSBTYW1wb



  GUgNmRkAggPZBYGZg8PFgIfEAUBN2RkAgEPDxYCHxAFDVNhbXBsZSBJdGVtIDdkZAICDw8WAh8QB



  SFaaW1tZXJncmVuJ3MgUGVyZm9ybWFuY2UgU2FtcGxlIDdkZAIJD2QWBmYPDxYCHxAFAThkZAIBD



  w8WAh8QBQ1TYW1wbGUgSXRlbSA4ZGQCAg8PFgIfEAUhWmltbWVyZ3JlbidzIFBlcmZvcm1hbmNlI



  FNhbXBsZSA4ZGQCCg9kFgZmDw8WAh8QBQE5ZGQCAQ8PFgIfEAUNU2FtcGxlIEl0ZW0gOWRkAgIPD



  xYCHxAFIVppbW1lcmdyZW4ncyBQZXJmb3JtYW5jZSBTYW1wbGUgOWRkAgsPZBYGZg8PFgIfEAUCM



  TBkZAIBDw8WAh8QBQ5TYW1wbGUgSXRlbSAxMGRkAgIPDxYCHxAFIlppbW1lcmdyZW4ncyBQZXJmb



  3JtYW5jZSBTYW1wbGUgMTBkZAIMD2QWBmYPDxYCHxAFAjExZGQCAQ8PFgIfEAUOU2FtcGxlIEl0Z



  W0gMTFkZAICDw8WAh8QBSJaaW1tZXJncmVuJ3MgUGVyZm9ybWFuY2UgU2FtcGxlIDExZGQCDQ9kF



  gZmDw8WAh8QBQIxMmRkAgEPDxYCHxAFDlNhbXBsZSBJdGVtIDEyZGQCAg8PFgIfEAUiWmltbWVyZ



  3JlbidzIFBlcmZvcm1hbmNlIFNhbXBsZSAxMmRkAg4PZBYGZg8PFgIfEAUCMTNkZAIBDw8WAh8QB



  Q5TYW1wbGUgSXRlbSAxM2RkAgIPDxYCHxAFIlppbW1lcmdyZW4ncyBQZXJmb3JtYW5jZSBTYW1wb



  GUgMTNkZAIPD2QWBmYPDxYCHxAFAjE0ZGQCAQ8PFgIfEAUOU2FtcGxlIEl0ZW0gMTRkZAICDw8WA



  h8QBSJaaW1tZXJncmVuJ3MgUGVyZm9ybWFuY2UgU2FtcGxlIDE0ZGQCEA9kFgZmDw8WAh8QBQIxN



  WRkAgEPDxYCHxAFDlNhbXBsZSBJdGVtIDE1ZGQCAg8PFgIfEAUiWmltbWVyZ3JlbidzIFBlcmZvc



  m1hbmNlIFNhbXBsZSAxNWRkAhEPZBYGZg8PFgIfEAUCMTZkZAIBDw8WAh8QBQ5TYW1wbGUgSXRlb



  SAxNmRkAgIPDxYCHxAFIlppbW1lcmdyZW4ncyBQZXJmb3JtYW5jZSBTYW1wbGUgMTZkZAISD2QWB



  mYPDxYCHxAFAjE3ZGQCAQ8PFgIfEAUOU2FtcGxlIEl0ZW0gMTdkZAICDw8WAh8QBSJaaW1tZXJnc



  mVuJ3MgUGVyZm9ybWFuY2UgU2FtcGxlIDE3ZGQCEw9kFgZmDw8WAh8QBQIxOGRkAgEPDxYCHxAFD



  lNhbXBsZSBJdGVtIDE4ZGQCAg8PFgIfEAUiWmltbWVyZ3JlbidzIFBlcmZvcm1hbmNlIFNhbXBsZ



  SAxOGRkAhQPZBYGZg8PFgIfEAUCMTlkZAIBDw8WAh8QBQ5TYW1wbGUgSXRlbSAxOWRkAgIPDxYCH



  xAFIlppbW1lcmdyZW4ncyBQZXJmb3JtYW5jZSBTYW1wbGUgMTlkZAIVD2QWBmYPDxYCHxAFAjIwZ



  GQCAQ8PFgIfEAUOU2FtcGxlIEl0ZW0gMjBkZAICDw8WAh8QBSJaaW1tZXJncmVuJ3MgUGVyZm9yb



  WFuY2UgU2FtcGxlIDIwZGQCFg9kFgZmDw8WAh8QBQIyMWRkAgEPDxYCHxAFDlNhbXBsZSBJdGVtI



  DIxZGQCAg8PFgIfEAUiWmltbWVyZ3JlbidzIFBlcmZvcm1hbmNlIFNhbXBsZSAyMWRkAhcPZBYGZ



  g8PFgIfEAUCMjJkZAIBDw8WAh8QBQ5TYW1wbGUgSXRlbSAyMmRkAgIPDxYCHxAFIlppbW1lcmdyZ



  W4ncyBQZXJmb3JtYW5jZSBTYW1wbGUgMjJkZAIYD2QWBmYPDxYCHxAFAjIzZGQCAQ8PFgIfEAUOU



  2FtcGxlIEl0ZW0gMjNkZAICDw8WAh8QBSJaaW1tZXJncmVuJ3MgUGVyZm9ybWFuY2UgU2FtcGxlI



  DIzZGQCGQ9kFgZmDw8WAh8QBQIyNGRkAgEPDxYCHxAFDlNhbXBsZSBJdGVtIDI0ZGQCAg8PFgIfE



  AUiWmltbWVyZ3JlbidzIFBlcmZvcm1hbmNlIFNhbXBsZSAyNGRkAhoPDxYCHwBoZGQYAgUfY3RsM



  DAkUGxhY2VIb2xkZXJNYWluJEdyaWRWaWV3MQ88KwAKAQgCKWQFR2N0bDAwJFBsYWNlSG9sZGVyV



  G9wTmF2QmFyJFBsYWNlSG9sZGVySG9yaXpvbnRhbE5hdiRUb3BOYXZpZ2F0aW9uTWVudVY0Dw9kB



  QRIb21lZGnihW5zRhNmmnQef2E5KXJlKgIU" />



If you compare the aforementioned ViewState with the very same page but with the ViewState disabled, it would look like this:

 <input type="hidden"



  name="__VIEWSTATE"



  id="__VIEWSTATE"



  value="/wEPDwULLTE5NjIxMzI1MDJkGAIFH2N0bDAwJFBsYWNlSG9sZGVy



  TWFpbiRHcmlkVmlldzEPPCsACgEIAilkBUdjdGwwMCRQbGFjZUhvbGRlclR



  vcE5hdkJhciRQbGFjZUhvbGRlckhvcml6b250YWxOYXYkVG9wTmF2aWdhdG



  lvbk1lbnVWNA8PZAUESG9tZWTEsK7AlAZmIZYt/bke1dmkbPKxhg=="/>



What impact can these few lines of markup have on the page rendering process anyway, you say? Well, in order to find out – let’s summon our good friend Fiddler2 and do a quick comparison.

ViewState Enabled

ViewState Disabled

Body size (bytes) 14 534 bytes 12 883 bytes
Load time (seconds) 0.3765430 seconds 0.2031263 seconds

A visual comparison of the same page with versus without ViewState enabled:

Body Size comparison (bytes)

Load Time comparison (seconds)

image image

So what can I do to tune and tweak the ViewState?

There’s generally two good initial tips for tuning the ViewState.

  • Disable ViewState for the entire page
  • Disable ViewState for selected components

The first option is good if you don’t need to use ViewState in any of the components on your page. Then you can simply disable ViewState by setting the ViewStateEnabled property to false:

  <%@ Page Language="C#"



     AutoEventWireup="true"



     CodeBehind="ViewStateSample.aspx.cs"



     Inherits="Zimmergren.Samples.ViewState.ViewStateSample"



     DynamicMasterPageFile="~masterurl/default.master"



     EnableViewState="false"  %>



The second option is good if you need the ViewState for certain components, but you want to disable it for others. You can disable the ViewState for specific components;

     <asp:GridView ID="GridView1"



         runat="server"



         AutoGenerateColumns="False"



         AllowSorting="true"



         AllowPaging="true"



         PageSize="25"



 EnableViewState="false"



         />



Additional Tip: Take a look at HTTP compression

In addition to being aware of the ViewState in any asp.net project, you should take a look at HTTP Compression that you can enable in IIS.

Read more on HTTP Compression

Summary

Alright – the summer is officially over (at least of you take a look at the recent weather) and I’m back in the saddle. In this article I’ve been talking a bit about how the ViewState can impact your performance in any asp.net project (hence SharePoint project). The reason for talking about it is that I’ve seen quite the amount of projects as of late that doesn’t think about the impact a huge ViewState can have on the time it takes to download and render a page on the client.

An important consideration that I’ve learned throughout all our projects to create Internet-facing sites based on SharePoint (or plain old ASP.NET) is to measure the performance in different scenarios, including some stress testing and load tests. In most of these projects we’ve seen an increased performance if we take time to select what components or pages should disable ViewState. It might be worth considering.

Note that this is a minimal sample with minimal impact. Consider when you’ve got a huge page with 10+ Web Parts and all using the ViewState, even if they don’t really need to – can you imagine the page load times increasing? The answer is probably yes :-)

Enjoy.

Author: Tobias Zimmergren
http://www.zimmergren.net | http://www.tozit.com | @zimmergren

Introduction

After many-a-requests I’ve decided to do an article on how you can work with an Azure-hosted SQL Server and consume that data in SharePoint 2010.

Related articles for working with external data in SharePoint 2010:

A few introductory details about this article…

In this article I will discuss and guide you through how you can utilize the power, scalability, flexibility and awesomeness that comes with the cloud. By following this article you will get an introduction to how you can work with SharePoint together with Windows Azure to store business data.

This article will be an introduction to developing SharePoint solutions to work with Windows Azure, and in later articles I will discuss other approaches where Windows Azure may be a good solution to incorporate in the plans for your organization together with Office 365 and SharePoint Online.

Please note that this article is NOT intended to be an introduction to setting up Windows Azure. Its an introduction to setting up the connection from SharePoint to SQL Azure. More in-depth articles are coming up later.

Prerequisites

In order to follow along with this article and repro these steps yourself, you will need to have the following things in place already:

  • A Windows Azure developer account
  • An SQL Azure database and a table in that database
  • Visual Studio 2010
  • SharePoint Designer 2010
  • A few sprinkles of awesomeness in your pocket would be nice, just for fun

Please note that in SQL Azure you’d need to hook up the IP-address of the machine running this code or service in order to enable it for connectivity with the SQL Azure database. You’ll see more about that in your SQL Azure portal.

Connect to SQL Azure using Business Connectivity Services in SharePoint 2010

In this section I will talk about how we can create a connection to our SQL Azure database from SharePoint by utilizing BCS. I will for the ease of demo use SharePoint Designer to set it up – and to prove that it works!

1. Make sure you’ve got existing data in one of your SQL Azure databases

In my setup, I’ve got a database called ZimmergrenDemo and a table called ProductSales. I can access the database either from the Windows Azure Platform portal or directly from the SQL Server Management Studio:



I’ve got some sample data that I’ve popped into the SQL Azure Database:


2. Setting up a Secure Store Service configuration for your SQL Azure connection

In order for the BCS runtime to easily be able to authenticate to the SQL Azure database (which is using different credentials than your Windows Server/Domain), you can create a Secure Store application and use that for authentication.

1. Create a new Secure Store Application

Go to Central Admin > Mange Service Applications > Secure Store Service > New

Create a new Secure Store application, looking something like this:

2. Configure the Secure Store application fields

I add one field for User Name and one for Password, something like this:


3. Add the administrator account(s) needed


Voila! Your Secure Store application is setup, now let’s move on to working with the data in our SQL Azure database.

3. Working with the data though Business Connectivity Services

Now that the SQL Azure database is available and your Secure Store application is configured, it’s time to get the BCS up and running with SharePoint Designer.

The first and foremost option to get up and running quickly is of course to hook up an External List and be able to see your data straight through the standard SharePoint UI.

For a detailed step-by-step instruction for the whole routine to set up a new BCS connection, please refer to my previous articles.

1. Configure the BCS connection using SharePoint Designer

Launch SharePoint Designer and create a new External Content Type and select the SQL option for the data source. Enter the information to your SQL Azure database and the application ID for your Secure Store application.

Connecting to your SQL Azure database through BCS via SPD:

Since you need to enter the credentials for your impersonated custom identity (the SQL Azure database credentials) – you’ll get this dialog:

Enter the credentials to your SQL Azure database:

Once that is taken care of, you will be able to follow the normal routines for configuring your BCS connection.

My SQL Azure database, right inside of SPD:

2. Create an external list and navigate to it in your browser

In whatever way you prefer, create an external list for this External Content Type and navigate to it. You will probably see a link saying “Click here to authenticate“.

Click the link, and you will be provided with this interface:


I probably don’t have to explain that this is where you’ll enter your SQL Azure User Name and Password to make sure your BCS connection authenticates to your SQL Azure database properly.

Okay, when the external list is created and you’ve configured the authentication – you’ll see your data flying in directly from SQL Azure into your SharePoint external list for consumption!


And as always, the coolest thing here is that it’s read and write enabled straight away – you can work with the items in the list much like normal items in any list. Sweet.

Consume the data programmatically from SQL Azure instead

If you don’t want to go with the BCS-approach and just do code directly instead then all you need to do is make sure that you wear the developer-hat and start hacking away a few simple lines of code.

Working with SQL Azure is like working with any other data source, so there’s really no hunky dory magic going on behind the scenes – it’s all just pretty basic.

Here’s a sample Web Part I created to collect the data from SQL Azure and display in SharePoint 2010.


Here’s most of what the code could look like:

     public partial class VisualProductSalesUserControl : UserControl
     {
         private const string connectionString = "Server=tcp:YOURSERVER.database.windows.net;Database=ZimmergrenDemo;User ID=Username@YOURSERVER;Password=myAwesomePassword++;Trusted_Connection=False;Encrypt=True;" ;
         private string selectCommand = "select * from ZimmergrenDemo.dbo.ProductSales;" ;
         private DataTable productSalesData = new DataTable ("ProductSales" );
         protected void FetchAndFill(string connectionString, string selectCommand)
         {
             using (var connection = new SqlConnection (connectionString))
             {
                 var adaptor = new SqlDataAdapter
                 {
                     SelectCommand = new SqlCommand (selectCommand, connection),
                 };



                 adaptor.Fill(productSalesData);
                 salesGrid.DataSource = productSalesData;
                 salesGrid.DataBind();
             }
         }
         protected void Button1_Click(object sender, System.EventArgs e)
         {
             FetchAndFill(connectionString, selectCommand);
         }
     }



Summary

In this article I talked briefly about how you can connect to your SQL Azure database using BCS and then utilize that information from SharePoint – or create a custom solution to access the data.

The reason for this article is to show you that working with Azure isn’t a big and scary task to take upon you – it’s actually all very straight forward!

Enjoy.

Author: Tobias Zimmergren
http://www.zimmergren.net | http://www.tozit.com | @zimmergren

Introduction

SharePoint 2010 developing for performance article series:
In this series of articles I will briefly introduce you to some key concepts when it comes to developing for performance in our SharePoint 2010 applications.

Related articles in this article series

Part 1 – SP 2010: Developing for performance Part 1 – Developer Dashboard
Part 2 – SP 2010: Developing for performance Part 2 – SPMonitoredScope
Part 3 – SP 2010: Developing for performance Part 3 – Caching in SharePoint 2010
Part 4 – SP 2010: Developing for performance Part 4 – Logging
Part 5 – SP 2010: Developing for performance Part 5 – Disposal patterns and tools
Part 6 – SP 2010: Developing for performance Part 6 – CSS Sprites
Part 7 – SP 2010: Developing for performance Part 7 – Crunching those scripts
Part 8 – SP 2010: Developing for performance Part 8 – Control that ViewState

Part 7 (this article):
This article is a bit shorter than the others and will only cover the concept of crunching your script files in your projects. The reasoning behind a crunched file is to save on transfer-bytes between the client and server.

JavaScript crunching

The technique called script crunching (or JavaScript crunching) is often referred to a way of eliminating useless characters from the script files to allow them to load faster. This means that by eliminating unnecessary whitespaces, line breaks and putting semicolons in the right places you can achieve a file size that is smaller than the original.

The reasoning behind crunching the script files are much that you can save on the client/server transfer and therefore also minimize the HTTP requests – which in turn is one step in the right direction for minimizing the page load time and render time.

Short in short; Do consider the technique if you’ve got large scripts that are taking a bit too long to load.

SharePoint 2010 are using crunched scripts

In SharePoint 2010 we already have a few examples of where JavaScript crunching is working in action. One example is the SP.js file which is essentially a crunched JavaScript library in SharePoint 2010. You do however also have the ability to use the SP.debug.js which contains the same content, but without being crunched.

When you look at those two files in an editor, you’ll quickly see the difference between them:

SP.js – 381 KB – Crunched JavaScript file in SharePoint 2010

SP.debug.js – 561 KB – The same file, but without the crunch

You can see that the mail difference between these two files is the file size. This means that if you’ve using the crunched version of the JavaScript file, your application will load slightly faster.

How to: Crunch your script files

There’s tons of tools on the market for crunching your scripts. Here’s a few online tools for crunching those scripts:

(or just search for JavaScript crunch, and you’ll find all the tools you’ll ever need)

What is the difference when using crunched scripts?

As a quick summary I did a test with an application that are loading a somewhat large script file – first without any crunching and then the same application loading the files after they’ve been minimized with a crunch. These are the results in my SharePoint 2010 application.

Without crunching

After crunching

JavaScript file size: 445871 bytes
(435 KB)
JavaScript file size: 331798 bytes
(324 KB)
  Saves around 25.5% in file size


Summary

A brief summary of the result is that if you’re crunching your script files, you’ll get a slightly smaller footprint when loading the page and making the HTTP requests. The reason for bringing this to your attention is of course that it’s a technique that’s been around for quite some time, but people tend to miss out on it because they’ve not seen the results of it. So, here you go – a visual chart telling you how it differs to use the exact same script, with and without crunching.

Enjoy.

Author: Tobias Zimmergren
http://www.zimmergren.net | http://www.tozit.com | @zimmergren

Introduction

The last week that just passed was filled with quite some cool happenings over at the BPCUK Conference in London. If you’ll follow the #BPCUK tag on Twitter you’ll find all the juicy information that you missed out on – there’s no real need for me to repeat it here :-)

Downloads

As promised, my session deck on Silverlight and SharePoint 2010 can be downloaded here: Download!

SP 2010: Developing for performance Part 6 – CSS Sprites

April 8th, 2011 by Tobias Zimmergren

Author: Tobias Zimmergren
http://www.zimmergren.net | http://www.tozit.com | @zimmergren

Introduction

SharePoint 2010 developing for performance article series:
In this series of articles I will briefly introduce you to some key concepts when it comes to developing for performance in our SharePoint 2010 applications.

Related articles in this article series

Part 1 – SP 2010: Developing for performance Part 1 – Developer Dashboard
Part 2 – SP 2010: Developing for performance Part 2 – SPMonitoredScope
Part 3 – SP 2010: Developing for performance Part 3 – Caching in SharePoint 2010
Part 4 – SP 2010: Developing for performance Part 4 – Logging
Part 5 – SP 2010: Developing for performance Part 5 – Disposal patterns and tools
Part 6 – SP 2010: Developing for performance Part 6 – CSS Sprites
Part 7 – SP 2010: Developing for performance Part 7 – Crunching those scripts
Part 8 – SP 2010: Developing for performance Part 8 – Control that ViewState

Part 6 (this article):
In web development today its very important to keep performance in mind – this is especially important in any site that is published externally or for whatever reason will have heavy traffic. In this article I will briefly cover the area of CSS Sprites, how they are implemented in SharePoint 2010 and of course how you can create them yourself.

Introduction to CSS Sprites

What are CSS sprites anyway?

CSS sprites is a technique used to reduce the number of requests for images on a site when visiting it. Normally when you see a web site today there’s plenty of files being requested and loaded upon the request made. With the use of CSS sprites we can reduce the amount of files that we need to request from the server by consolidating many image files into one file and use CSS to display the correct part of that consolidated image when it needs to depict your specific image.

Short in short: Take a bunch of separate images and smack them together to one single file. Voila, you’ll only need to request one file from the server.

SharePoint 2010 and CSS Sprites

So why are we talking about CSS sprites here anyway, isn’t this supposed to be all about SharePoint and awesomeness? But of course, and that’s exactly why we’re talking about it – CSS sprites are a natural part of a normal SharePoint 2010 installation. By default, there’s CSS sprite techniques used to render and display images in (for example) the Ribbon menu.

These are some samples of images used with CSS sprites in SharePoint 2010:

FGIMG.PNG jsgridcluster.png
FGIMG jsgridcluster

As you can see in any of the two images above the many small images/icons have been smashed together into one single image file and then there’s some CSS magic to position it. This is basically what it’s all about.

Why should I bother learning to use CSS sprites?

This would be like asking yourself the question "Why would I develop something that is of great performance" or "Why would I do something awesome". No more rhetorical questions please ;-)

Of course the reasoning behind creating CSS sprites are that you can develop web applications that can reduce the page load and enhance the performance of your sites and make them load quicker and be more responsive.

Creating CSS sprites for my applications? How?

There’s a few ways to create CSS sprites for you own applications.

  • Do it manually.
    • This approach requires a lot from you (the designer) in order to hack it up properly and make sure it’s pixel-correct.
  • Do it using a tool
    • This approach is what I normally use.
    • With any of the tools on the market to create CSS sprites you’re better off than doing it manually – all you have to do is dump you images into an application and it’ll output one single image along with the CSS markup for that. Awesome.

For obvious reasons mentioned above I will not be demonstrating how to do this manually but will rather be using any of the hundreds of tools out there to create the sprites.

In this example I’m going to use my main man Waldek’s tool called SpriteGenerator.

There’s a bunch of other tools available to create and generate these sprites as well of course, bing.com is thy friend.

How to: Generate CSS sprites using a tool

In this section I’ll talk you through our current application and what it looks like, what we want to achieve and finally how to achieve it.

Our current application, a visual sample

This is my current sample application before we start using sprites.

Control Panel Web Part (dummy):

This is the Visual Studio project, containing all the images and resources:

As you can see there’s quite some images being loaded. The images used in the application (my Web Part) will be fetched using a normal HTTP-request and that’s when one could realize how quickly those small requests can add up to impact performance.

This application uses some generic HTML markup like this:

         <div  class="width300p">
             <div  class="leftalign floatleft width30">
                 <div  class="height70p"><asp:Image  ID="Image2"  runat="server"  ImageUrl="/_layouts/images/TOZIT.CSSSprites/mail.png"  /></div>
                 <div  class="height70p"><asp:Image  ID="Image3"  runat="server"  ImageUrl="/_layouts/images/TOZIT.CSSSprites/message.png"  /></div>
                 <div  class="height70p"><asp:Image  ID="Image4"  runat="server"  ImageUrl="/_layouts/images/TOZIT.CSSSprites/more.png"  /></div>
             </div>
             <div  class="centeralign floatleft width30">
                 <div  class="height70p"><asp:Image  ID="Image5"  runat="server"  ImageUrl="/_layouts/images/TOZIT.CSSSprites/notebook.png"  /></div>
                 <div  class="height70p"><asp:Image  ID="Image9"  runat="server"  ImageUrl="/_layouts/images/TOZIT.CSSSprites/search.png"  /></div>
                 <div  class="height70p"><asp:Image  ID="Image13"  runat="server"  ImageUrl="/_layouts/images/TOZIT.CSSSprites/favorites.png"  /></div>
             </div>
             <div  class="width30 floatright">
                 <div  class="height70p"><asp:Image  ID="Image6"  runat="server"  ImageUrl="/_layouts/images/TOZIT.CSSSprites/info.png"  /></div>
                 <div  class="height70p"><asp:Image  ID="Image7"  runat="server"  ImageUrl="/_layouts/images/TOZIT.CSSSprites/logoff.png"  /></div>
                 <div  class="height70p"><asp:Image  ID="Image8"  runat="server"  ImageUrl="/_layouts/images/TOZIT.CSSSprites/question.png"  /></div>
             </div>
         </div>

Now, in order for us to utilize the CSS sprites instead, and not have to make a request for each of the images separately – we’ll use the SpriteGenerator and create us some nice CSS sprite magic.

Using the Sprite Generator to make some magic

Like I said before, we’ll be using Waldek’s SpriteGenerator for this sample.

Just open it, put in the images you’d like for it to make some magic with and then simply hit the magic button.

Tip: Check out how to use the SpriteGenerator here

The result of using the SpriteGenerator can look something like this:

This is one consolidated image containing all the graphic from my application. But instead of having about 30 different icons in my project, I now have only one.

The generator will create the CSS needed as well, and it can look something like this:

.sprite { background: url(‘/_layouts/images/TOZIT.CSSSprites/TOZIT_Sprite.png’) no-repeat top left; }
.pc { background-position: -0px 0; width: 47px; height: 64px; }
.question { background-position: -47px 0; width: 53px; height: 64px; }
.info { background-position: -100px 0; width: 54px; height: 64px; }
.mail { background-position: -154px 0; width: 54px; height: 64px; }
.more { background-position: -208px 0; width: 54px; height: 64px; }
.user { background-position: -262px 0; width: 55px; height: 64px; }
.world { background-position: -317px 0; width: 55px; height: 64px;  }
.video { background-position: -372px 0; width: 56px; height: 64px; }
.favorites { background-position: -428px 0; width: 57px; height: 64px; }
.edit { background-position: -485px 0; width: 60px; height: 64px; }
.date { background-position: -545px 0; width: 64px; height: 57px; }
.file { background-position: -609px 0; width: 64px; height: 64px; }
.group { background-position: -673px 0; width: 64px; height: 58px; }
.home { background-position: -737px 0; width: 64px; height: 62px; }
.left_arrow { background-position: -801px 0; width: 64px; height: 59px; }
.logoff { background-position: -865px 0; width: 64px; height: 78px; }
.notebook { background-position: -929px 0; width: 64px; height: 51px; }
.rigth_arrow { background-position: -993px 0; width: 64px; height: 57px; }
.search { background-position: -1057px 0; width: 64px; height: 61px; }
.sound { background-position: -1121px 0; width: 64px; height: 58px; }
.stop { background-position: -1185px 0; width: 64px; height: 59px; }
.vault { background-position: -1249px 0; width: 64px; height: 53px; }
.message { background-position: -1313px 0; width: 66px; height: 64px; }
.image { background-position: -1379px 0; width: 84px; height: 84px; }
.tozitlogo { background-position: -1463px 0; width: 250px; height: 101px; }

Now, what this really means is that you now have the ability to actually use only one single image to portray several.

New Visual Studio structure

Obviously, with the new update and only using one single image – the Visual Studio project might look something like this:


New HTML markup

And finally, there needs to be some changes in the HTML markup to reflect the changes with the images. The markup could look something like this:

         <div  class="leftalign floatleft width30">
             <div  class="height70p sprite mail">&nbsp;</div>
             <div  class="height70p sprite message"  >&nbsp;</div>
             <div  class="height70p sprite more"  >&nbsp;</div>
         </div>

How does using CSS Sprites affect requests, hence performance?

Dealing with sprites isn’t very hard to get started with as you saw in the previous short samples. But what’s more interesting from a performance perspective is of course how it can affect the performance of the requests being made towards the server.

Let’s do some generic Fiddler-magic to see what the requests look like without using sprites and then what the requests look like with the use of sprites.

Fiddler test 1: NOT using CSS sprites


Request Count 17 total requests made to the server!
Bytes Sent 8 137 bytes
Bytes Received 76 164 bytes

Fiddler test 2: Using CSS sprites


Request Count 3 total requests made to the server!
Bytes Sent 1 722 bytes
Bytes Received 139 369 bytes

What you can easily conclude from the initial tests is that there’s more requests without the CSS sprites, while the size can be slightly larger for a consolidated image when using the sprites.
It’ll load and render quicker by downloading only the 3 files instead of the 17 files due to the aggregation time it takes to render the content.

Visualize the results, please!

Using CSS sprites
(Time in seconds to load the data)
NOT using CSS sprites
(Time in seconds to load the data)
image image

RESPONSE BYTES
image/png:    120 250
text/html:    16 593
~headers~:    1 748
text/css:    778

RESPONSE BYTES
image/png:    52 417
text/html:    16 709
~headers~:    6 260
text/css:    778

ACTUAL PERFORMANCE
Aggregate Session time:
00:00:00.531 (0.5 seconds)
Sequence (clock) time:
00:00:00.4281250 (0.4 seconds)

ACTUAL PERFORMANCE
Aggregate Session time:
00:00:01.390 (1.3 seconds)
Sequence (clock) time:
00:00:00.5625000 (0.5 seconds)

I did some tests with two machines, two different projects and a couple of clients to request the pages and the results (on average) was something like this in rendering time. The chart below is a relative visualization of the results per average.

Chart

Summary

The impact of a system with a lot more requests for data than these samples, more users and in generally more traffic would differ a bit more than the charts here. Using sprites in combination with caching the data is a good practice to keep the amount of requests to the server to a minimum.

Even if this minor change don’t have any critical impact on improving the performance it’s important to consider. "All improvements are good improvements".

Author: Tobias Zimmergren
http://www.zimmergren.net | http://www.tozit.com | @zimmergren

Introduction

It probably doesn’t surprise anyone that the BPC conference in London is one of the main events to look forward to in the realm of SharePoint conferences.

I will of course be attending this conference and I’ll be delivering an introductory  session about Silverlight and SharePoint.

My session: Developing with Silverlight + SharePoint 2010 = Awesome

I’ll be talking about how you can utilize Silverlight in SharePoint 2010 to create some cool RIA applications hosted inside (or outside!) of SharePoint.

In this session you’ll get acquainted with what Silverlight is and how it plays along with SharePoint 2010 in various ways.

We’ll of course be looking at how to create our very own Silverlight Web Parts and applications and host them inside of SharePoint 2010.

The preliminary agenda of the session looks something like this;

  • Silverlight 101
  • Integrate with SharePoint 2010
  • Preferred deployment methods and developer guidance
  • Developer patterns
  • OOB Experience (Out of Browser) – Bring your Silverlight app to your desktop
  • And much more

Last years conference (Evolutions conference)

Just like you already know there was a volcano that found it suitable to erupt just in time for the conference last year that put a cane in the wheels for a lot of the attendees and speakers.

My flights were cancelled in last minute so I had to find another way of making my way to the conference last year. One day before the conference I basically gave up hope and I just posted a tweet on Twitter saying "Hey, I need to go from Sweden to England, any takers?".

A few minutes later a good friend of mine calls me up saying "Hey, I’m going to The Netherlands to pick up my girl since the flights are cancelled and boats and trains are full. I’m leaving in a few hours by car toward NL. Care to join?"

Alright, why not I thought… We drove from Sweden through Denmark, Germany and finally reached Rotterdam in Holland after a long journey. This is where he picked up his girl and were bound to head back to Sweden again.

I’m dropped off there, in the middle of nowhere, without any means of getting back to Sweden or getting on to England. All the boats and trains were full, remember?
This is where I’m using Twitter again and post a tweet asking if anyone is in Rotterdam and will be driving to England in the near future.

Marianne tweets me back saying "Hey, we’ve got a spare seat in the car, we’ll pick you up tomorrow at 08.00 outside your chosen hotel". Sweet! Now we’re talking.

We drove from Holland through Belgium and France to finally take the Eurotunnel and reach England.

Even though that trip was a real blast and can’t really be depicted in words here, I really hope that the flights are leaving as scheduled this time!

Steve explaining the long journey

Summary

So if you’re attending BPC UK this year and care to join us in our adventures in the SharePoint jungle and the pubs – ping me.

This year I’m counting on the flights and I’m hoping to see as many of you as possible for the conference in London next week.

Until then, be awesome.

Author: Tobias Zimmergren
http://www.zimmergren.net | http://www.tozit.com | @zimmergren

Introduction

Some exiting news is about to be published and I’m glad to announce that some fantastic plans we’re working on is about to take shape. As stated in the headline of this post, TOZIT AB is now hiring staff in Sweden. We’re looking for sales representatives, consultants and helpdesk colleagues.

TOZIT AB is located in Sweden with it’s main office in Malmö, and operates a lot in Stockholm. The persons we’re looking for initially should be able to work either in Malmö/Öresundsregionen or Stockholm.

At TOZIT we are always looking to deliver high quality projects and resources, but not without having a great time doing so. The first and foremost policy we’ve got is to enjoy every day you work with us.

We invest in our employees making sure they are top of the line and always up to date with what’s new in the SharePoint world. By joining TOZIT AB, we will make sure that you get the latest and greatest training to make sure you’re on top of the latest technology.

#1: SharePoint specialist

If you’re aspiring to be a solid SharePoint professional and want to work together with some of the brightest minds when it comes to .NET and SharePoint, this is an opportunity you don’t want to miss out on.

Job Requirements

  • Basic understanding of SharePoint infrastructure, design and development.
  • Additional merits include:
    • Real world SharePoint project experience
    • .NET development experience
    • .NET and SharePoint Certifications (MCP, MCPD, MCITP, MCTS, MCT, …)

Job Location

This job opening applies to people able to work in one of the following locations:

  • Stockholm
  • Malmö/Köpenhamn/Öresundsregionen

Application Details

Please send your application to jobs@tozit.com if you’re interested in learning more about this position and what we can offer you. Please attach your updated resume (CV) along with any additional data (LinkedIn profile for example).

#2: Senior SharePoint specialist

If you’re a senior SharePoint professional looking for new challenges, perhaps we could fit you in our team.

In this role we will expect you to have a vast experience from the field as a consultant or freelancer and have been working with a lot of real world projects that you can showcase or talk about.

Job Requirements

  • 4+ years of experience with professional SharePoint projects
  • Additional merits include:
    • .NET development
    • Certifications (MCP, MCPD, MCITP, MCTS, MCT, …)

Job Location

This job opening applies to people able to work in one of the following locations:

  • Stockholm
  • Malmö/Köpenhamn/Öresundsregionen

Application Details

Please send your application to jobs@tozit.com if you’re interested in learning more about this position and what we can offer you. Please attach your updated resume (CV) along with any additional data (LinkedIn profile for example).

#3: Technical helpdesk

We’re currently also looking for someone to work with support and helpdesk, where your main responsibility will be to make sure the internal systems work properly and assist the different departments in their daily routines.

Job Requirements

  • You should most definitely be service minded
  • A technical background with Microsoft technologies is preferred

Job Location

This job opening applies to people able to work in central Stockholm only.

Application Details

Please send your application to jobs@tozit.com if you’re interested in learning more about this position and what we can offer you. Please attach your updated resume (CV) along with any additional data (LinkedIn profile for example).

#4: SharePoint sales representative

We’re looking to extend our sales team with one or more additional resources to help out and assist in the sales and finding new leads on projects, and help close new deals with new and existing customers.

Job Requirements

You’re a sales representative with focus on quality instead of quantity and knows how to listen to the clients requirements and can match that with what we can offer. You should have a network to utilize for finding new projects and clients and being able to find new leads.

Job Location

  • Malmö (with the possibility to work in Stockholm sometimes)

Application Details

Please send your application to jobs@tozit.com if you’re interested in learning more about this position and what we can offer you. Please attach your updated resume (CV) along with any additional data (LinkedIn profile for example).

Summary

We’re looking to extend our team and the level of services we provide by employing some new colleagues to work with us in our awesome team. If you’d like to work with me and my team and want to have fun while doing so, please don’t hesitate to send your application to us :-)

Author: Tobias Zimmergren
http://www.zimmergren.net | http://www.tozit.com | @zimmergren

Introduction

SharePoint 2010 developing for performance article series:
In this series of articles I will briefly introduce you to some key concepts when it comes to developing for performance in our SharePoint 2010 applications.

Related articles in this article series

Part 1 – SP 2010: Developing for performance Part 1 – Developer Dashboard
Part 2 – SP 2010: Developing for performance Part 2 – SPMonitoredScope
Part 3 – SP 2010: Developing for performance Part 3 – Caching in SharePoint 2010
Part 4 – SP 2010: Developing for performance Part 4 – Logging
Part 5 – SP 2010: Developing for performance Part 5 – Disposal patterns and tools
Part 6 – SP 2010: Developing for performance Part 6 – CSS Sprites
Part 7 – SP 2010: Developing for performance Part 7 – Crunching those scripts
Part 8 – SP 2010: Developing for performance Part 8 – Control that ViewState

Part 5 (this article):
In SharePoint 2010 (and 2007 for that matter) there’s a few objects in the API’s that requires your special attention in order to behave properly. If you do not consider the disposal patterns and rules set forth, your application may very well suffer performance issues. In this article I will briefly touch upon the subject of disposing your SharePoint objects and foremost enlighten how important it is to dispose the objects!

What does Disposing mean and why is it important?

When I deliver training, there’s always the question about why disposing is important. In SharePoint there’s valid grounds for saying it’s important to dispose, more than just saying "It’s best practice". If you don’t properly dispose some of your objects in SharePoint you’ll quickly face performance issues since those objects don’t get caught and disposed by the Garbage Collector in a timely fashion as most other objects do in .NET.

What is a "dispose pattern"?

http://en.wikipedia.org/wiki/Dispose

The Dispose Pattern is the approach used to properly dispose and clean up the resources you’re using in your projects when programming in .NET (or other runtimes). Normally there’s an automatic garbage collector doing the cleanup for you – but in certain scenarios (like the ones described later in this article), you’ll need to manually dispose your objects.

IDisposable

In Microsoft .NET when an object inherits from the IDisposable interface it means that the Garbage Collector will call the .Dispose() method of that object when it’s no longer used. The Dispose() method in turn calls the Close() method which generally means you should call the .Dispose() method instead of the .Close() method to make sure the objects are properly disposed. Keep reading to see why this is so important!

Why is manual disposal really, really important in SharePoint?

Some of the objects you’re working with heavily in the SharePoint object model (for example the SPWeb and SPSite) are mostly using unmanaged code – and since the managed part of the code is quite small it doesn’t leave a large memory footprint and hence the Garbage Collector don’t necessarily dispose of that object – which means that it’ll be occupying server resources for a longer time if you don’t manually dispose of those objects.

What happens if I forget to dispose?

There’s several things that you may notice in your applications if you’ve implemented a solution that are not properly disposing their objects.

  • Memory consumption.
    • The consumption of your server memory may peak and the worker process (w3wp.exe) may consume a lot more memory than it would normally have to consume.
  • Application Pool recycling.
    • If the worker process consumes too much memory, it’ll recycle the application pool.
    • If you’ve got an underperforming application causing overwhelming  memory consumption the Application Pool will recycle more often.
  • Performance issues!
    • Slow response times
    • Timeouts
    • Unexpected errors
  • Headache
    • User headache
    • Support headache
    • Admin headache
    • Developer headache (ultimately)

In other words: Make sure you’re properly disposing your objects at all times!

Sandboxed Solutions and Resource Usage – Think about dispose patterns!

If you’re developing applications for the Sandbox in SharePoint 2010 (User Code Solutions / Sandboxed Solutions) you may be aware of the resource point system that will limit your application’s usage of resources on the server. This is a great way to keep the admins calm and developers keen on producing quality code.

A thing to note is that if you don’t correctly dispose your objects they will consume more server resources which in turn would lead to the resource points increasing. If the resource usage reaches the limits set forth by SharePoint for a sandboxed solution – it’ll deactivate it.

In other words: Make sure you’re properly disposing your objects at all times!

Let’s visualize the performance problem!

Okay, so now that I’ve got your attention – let’s do a quick performance test to see how the process handles the memory if we create the same application with and without disposal patterns in SharePoint.

I created a simple application that will work heavily with the SPSite and SPWeb objects on one of my servers. After hooking up a performance counter and monitoring the memory consumption repeatedly during a few hours of repeated execution it was easy to line down a conclusion which you can see in the chart below.

Performance summary

The following chart displays the same application with and without implementing the dispose patterns in a SharePoint 2010 execution environment.

Zimmergren Sample Memory Consumption Chart

You can see by the results of the two applications above that when we’re properly disposing our objects there’s a notable difference in the performance in our application – and hence the overall server resource usage.

In other words: Make sure you’re properly disposing your objects at all times!

How to: Implement dispose patterns in your SharePoint code

At this point we know it’s very important to dispose our objects in SharePoint – let’s take a look at how we can do that properly and what tooling and guidelines we can use to help us in this important quest!

Approach 1 – Manually calling Dispose()

The absolutely most general and simple approach to dispose your objects is to simply call the .Dispose() method of your objects:

 SPSite  site = new  SPSite ("http://zimmergren/");
 // Do stuff
 site.Dispose();

Approach 2 – Encapsulating the statement in a using() block

A more common approach is to encapsulate the code in a using-block where the object will be automatically disposed when we’re reaching the end of our block.

     using (SPSite  site = new  SPSite ("http://zimmergren"));
     {
         // Do stuff
     }

Approach 3 – Utilize a try/finally block

Whenever you’re expecting to catch an exception or somehow might stumble onto exceptions and need to handle them – a better approach for disposing is to create a try-finally block and dispose the object in the finally-block.

Sample 1: Without exception handling

     SPSite  site = null ;
     try
     {
         site = new  SPSite ("http://zimmergren");
         // do stuff
     }
     finally
     {
         if (site!=null ) site.Dispose();
     }

Sample 2: With exception handling

     SPSite  site = null ;
     try
     {
         site = new  SPSite ("http://zimmergren");
         // do stuff
     }
     catch (Exception  ex)
     {
         // Handle the exception
         // Possibly send it to the logs
     }
     finally
     {
         if (site!=null ) site.Dispose();
     }

SharePoint 2010 Logging information: http://zimmergren.net/archive/2011/01/17/sp-2010-developing-for-performance-part-4-logging.aspx

Approach 4 – A mix of the aforementioned approaches

In some scenarios it might be a necessity to mix the aforementioned methods for disposing.

     using (SPSite  site = new  SPSite ("http://zimmergren"))
     {
         foreach (SPSite  oSite in  site.WebApplication.Sites)
         {
             try
             {
                 // Do stuff
             }
             catch (Exception  ex)
             {
                 // Log and handle exceptions
             }
             finally
             {
                 if (oSite!=null ) oSite.Dispose();
             }
         }
     }

Using SPDisposeCheck.exe to help us check for issues

It’s one thing to be pro-active and think about the dispose patterns when you’re developing your applications – but sometimes you can’t cope for every scenario in your complex code. Don’t worry though – you’ve got one of my best friends to help you out with that – the SPDisposeCheck.exe tool that Microsoft released to check for disposal problems.

Download and install it

There’s a new version of the popular dispose-check tool for SharePoint called SPDisposeCheck. You can find it here: http://code.msdn.microsoft.com/SPDisposeCheck

Grab your copy of the tool and hang on tight for the ride!

Configure it

When you’ve installed the tool, you can see a new menu option in the "Tools" menu:


Clicking the "SharePoint Dispose Check" menu item will bring up the SPDisposeCheck configuration menu like this:


In this dialog you can configure how the tool should behave, and if it should execute after each build. What’s even cooler is you can choose how to treat the problems.

When you’re building your Visual Studio project, the SPDisposeCheck will perform a post-build command (if you’ve ticked the Execute After Build checkbox) – and you’ll see the output directly in your Error-window:


Tip!
Always have this tool installed, and every now and then run the SPDisposeCheck to make sure your code is properly disposing your objects. Otherwise it’ll warn you like in the picture above :-)

False positives

When it comes to checking for dispose problems or leaks with this tool, it can sometimes give you something you’d refer to as "a false positive". What that generally means is that although the tool might report a problem, it really isn’t.

Ignoring reports

Sometimes with the SPDisposeCheck tool you’ll get quite a bunch of "false positives" reported, or for whatever other reason you’d like to ignore certain error messages from the SPDisposeCheck tool – you can do that by implementing the SPDisposeCheckIgnore attribute (available as source code in the SPDisposeCheck installation folder).

The following code snippet is taken from the "SPDisposeCheckIgnoreAttribute.cs" file in the SPDisposeCheck installation folder. Add this code to your project (you can change the namespace..):

 using  System;
 namespace  Zimmergren.SP2010.DisposePatterns
 {
     public  enum  SPDisposeCheckID
     {
         // SPDisposeCheckIDs.
         SPDisposeCheckID_000 = 0,
         SPDisposeCheckID_100 = 100,
         SPDisposeCheckID_110 = 110,
         SPDisposeCheckID_120 = 120,
         SPDisposeCheckID_130 = 130,
         SPDisposeCheckID_140 = 140,
         SPDisposeCheckID_150 = 150,
         SPDisposeCheckID_160 = 160,
         SPDisposeCheckID_170 = 170,
         SPDisposeCheckID_180 = 180,
         SPDisposeCheckID_190 = 190,
         SPDisposeCheckID_200 = 200,
         SPDisposeCheckID_210 = 210,
         SPDisposeCheckID_220 = 220,
         SPDisposeCheckID_230 = 230,
         SPDisposeCheckID_240 = 240,
         SPDisposeCheckID_300 = 300,
         SPDisposeCheckID_310 = 310,
         SPDisposeCheckID_320 = 320,
         SPDisposeCheckID_400 = 400,
         SPDisposeCheckID_500 = 500,
         SPDisposeCheckID_999 = 999
     }

     [AttributeUsage (AttributeTargets .Method | AttributeTargets .Assembly,
         Inherited = false , AllowMultiple = true )]
     public  class  SPDisposeCheckIgnore  : Attribute
     {
         public  SPDisposeCheckIgnore(SPDisposeCheckID  Id, string  Reason)
         {
             _id = Id;
             _reason = Reason;
         }

         protected  SPDisposeCheckID  _id;
         protected  string  _reason;

         public  SPDisposeCheckID  Id
         {
             get  { return  _id; }
             set  { _id = Id; }
         }

         public  string  Reason
         {
             get  { return  _reason; }
             set  { _reason = Reason; }
         }
     }
 }


Once you’ve done that, you can use the attribute on your methods and assemblies to tell them to ignore that specific item.

Example usage of the SPDisposeCheckIgnore attribute:

         [SPDisposeCheckIgnore (SPDisposeCheckID .SPDisposeCheckID_110,
             "False Positive, nothing to see here, move along!" )]
         private  static  void  MyAwesomeMethod()
         {
             // Your method code with false positives
         }


What if I’m an awesome coder already?

Too many times have I encountered problems in projects due to not properly checking for memory leaks.

Better safe than sorry. That’s all I’m going to say about that :-)

Summary & Links

What we’ve learned from this article is that you should always keep in mind how you handle your objects in your code – and especially when it comes to the SharePoint objects that are invoking unmanaged code like the SPWeb and SPSite objects (to name two common ones).

Make sure you’ve downloaded the latest version of the SPDisposeCheck tool to get the aforementioned fancy integration into Visual Studio 2010. It’s pretty awesome indeed!

Links / Resources

Enjoy!
